详细说明
| Technische Daten: | Technical data | 技术参数 | |
| steckverbindersystem | Connector System | 金属插头系统 | ￠8mm |
| Bemessungspannung | Rated voltage | 额定电压 | 1000V DC |
| Bemessungsstrom | Rated current | 额定电流 | 350A/300A/250A/200A/125A/80A/65A |
| Prufspannung | Test voltage | 测试电压 | 4kV(50Hz,1min.) |
| Umgebungstemperaturbereich | Ambient temperature range | 环境温度范围 | -30℃…+50℃ |
| Obere Grenztemperatur | Maximum temperature | 温度上限 | +105℃ |
| Schutzart,gesteckt | Protection rating (Connector Engaged) | 防护等级,插合状态 | IP44(mated) |
| Ungesteckt | Touch protection rating | 触摸保护 | IP2X |
| Kontaktwiderstand der Steckverbinder | Connector contact resistance | 连接器接触阻抗 | 0.35mΩ Max(DC) |
| Schutzklasse | Safety rating | 安全等级 | Ⅱ |
| Kontaktmaterial | Terminal material | 端子材料 | CopperAlloy,Silver plated |
| Isolationsmaterial | Insulation material | 绝缘材料 | PA66 |
| Verriegelungssystem | Locking system | 锁紧系统 | Snap-in |
| Flammklasse | Flame class | 火焰等级 | UL-94-VO |
| Salznebelsprühtest,Scharfegrad 5 | Level 5 severe salt spray corrosion test | 腐蚀试验等级 | IEC 60068-2-52 |
| TÜV-Zertifiert | TUV-Recognized | TUV认证编号 | R50627666 0001 |
| Insertion/withdrawal force | 插拔力 | <100N |
电动出行，绿色未来！泰格莱的充电枪解决方案，让您的电动汽车充电更便捷、高效。
