Detail intruduction
| Technische Daten: | Technical data | 技术参数 | |
Steckverbindersystem | Connector system | 金属插头系統 | ￠6.35*1.5mm |
| Bemessungsspannung | Rated voltage | 额定电压 | 125V AC |
Bemessungsstrom | Rated current | 额定电流 | 15A(14AWG)，13A(16AWG) |
| Prufspannung | Test voltage | 测试电压 | 1250V(40Hz 70Hz 1minute) |
Umgebungstemperaturbereich | Ambient temperature range | 环境温度范围 | -40℃~+50℃ |
| Obere Grenztemperatur | Maximum temperature | 温度上限 | +105℃ |
Schutzart,gesteckt | Protection rating (Connector Engaged) | 防护等级插合状态 | IP20 |
| Kontaktwiderstand der Steckverbinder | Connector contact resistance | 连接器接触阻抗 | 10m OHMS |
Schutzklasse | Safetyrating | 安全等级 | Ⅱ |
| Kontaktmaterial | Terminal material | 端子材料 | Copper alloy,Nickel plating |
Isolationsmaterial | Insulation material | 绝缘材料 | PBT |
| Flammklasse | Flame class | 火焰等级 | 94-V0 |
Salznebelsprühtest,Scharfegrad5 | Level 5 severe salt spray corrosion test | 腐蚀试验等级 | IEC 60068-2-52 |
| UL-Zulassung | UL-Recognized | UL认证编号 | E544677 |
